Specifications

• Structure:

Combination of post tensioned and RCC framed structure. Parking in 3 Basements

The offices are spread over from Ground floor to Eight upper floors

Staircases and lifts connect from basement to all levels

• Finishes:

Ground Floor Main Entrance Lobby: Granite / Marble flooring

Main Staircase-Basement floor to all floors: Granite flooring

Service Staircase-Basement floor to all floors: Kota stone

All Interior wall faces: Plastered and smoothly finished

• Ceilings:

Plasterboard finished and painted, concrete soffit to be sealed above false ceilings, exposed concrete soffit to be finished and painted smooth

• Exterior fascia of the Building:

Double glazed Structural floor to floor glazing with alucobond or similar cladding panels at floor edge and ceiling void / feature granite cladding as per elevations & textured surfaces in selective places, as per design to give an elegant look.

• Staircase & Hand Railings:

Mild Steel Railings to Architects design

• Fittings:

Toilet facilities for gents & ladies - Counter wash basins with cold water [good quality vitreous pastel colored ceramic ware] with bottle trap, good quality vitreous pastel colored wall mounted EWC (includes seat cover, flush valve [button type] and health faucet) & vitreous pastel colored urinals for men’s toilets

• Pantry:

Fully tiled pantry with waste outlet and water supply points for sink with water outlet provision for water purifier above drain board location.

• Others:

Electrical - Best quality cables / wiring through PVC conduits concealed in walls and ceilings for service parking and common areas only. Wiring for tenants’ space shall be as per their requirements and in their scope of works. Electrical floor panel for individual tenant is located in the electrical room on that particular floor. Circuiting and looping would be terminated in the electrical room. Beyond that work would be in the tenant’s scope. Total power available is 3000kva.

• DGs:

Two DG’s of 1600kva capacity (100% back-up.)

• Elevators:

3 nos. of Hi-speed Automatic passenger lifts of 1.75m/s speed with stainless steel mirror finish & 1 no. of service lift with off white painted interior finish & good interiors with Intercom facility connected to security cabin.

• Air Conditioning System:

Provided with centralized air conditioning system chilled water flow and return to the services entry point for each floor fed from centrally located air cooled chillers.

• Ventilation System:

Basement floors are provided with the combination of natural & forced ventilation systems.

Toilets shall be mechanically ventilated by means of sheet metal ducting and exhaust valves connected to exhaust fans located in each floor.

• Water Supply:

BWSSB / Borewells - Adequate capacity of underground sumps & overhead tanks

• Building Management System:

Car-parking entry to the complex through automatic boom barrier

To detect mal-functioning of lifts and location of lift stuck in the block and floor

To monitor all overhead and underground tank water levels

To monitor the chillers performance

To monitor the power and water consumption

Integrated security system for the complex. Vigilance on peripherals, basements, lift lobbies and stair lobbies through CCTV/cameras.

• Fire Fighting System:

As per fire norms fire detection and alarm, full sprinklers & public address system will be provided.
